hertz

ML Power 5

950 W total power | 4 x 100 + 1 x 550 W @ 2ohm | D-class
Was:
€575,00
Adding to cart… The item has been added
In stock
Free shipping from 100€
Free returns within 60 days
3-year warranty

Description

Mille power amplifiers are born to fully enhance the outstanding performance of the Mille speakers. The new ADC (ADVANCED D-CLASS TECHNOLOGY) ensures pure listening pleasure while keeping a compact size with unmatched power efficiency. The heat sink, engineered with double technology, extrusion and aluminium die-casting, enables the Mille Power amplifiers to work constantly at full power without ever overheating, further maximizing thermal efficiency. The ultra-versatile Hertzaudio car amplifier ML Power 5 (100 W x 4 + 550 W 2 ohm) provides the ability to drive a Mille system including the subwoofer. The HRC BM (Hertz Remote Control Bass Management), low frequencies level remote control, is optional.
Dimension 1 349
Dimension 2 332
Dimension 3 170
Dimension 5 148
Dimension 6 46.7
ML Power 5 - D-CLASS 5 CH. AMPLIFIER 4x100W+1x550W
<ol> <li>ADC (Advanced D-Class Technology) ensures hi-end acoustic response with unmatched power efficiency.</li> <li>Thermally optimized double extruded heat sink featuring die-cast aluminium ergonomic terminals.</li> <li>100 W x 4 + 550 W x 1
Channels 5
Filter Pass C C Ch filters: Lo-Pass 50 ÷ 500 Hz @ 24 dB/Oct.
A Ch filters: Full / Hi-Pass / Band-Pass 40 ÷ 150 Hz (HI) 80 ÷ 3.3k Hz (LO) @ 12 dB/Oct.
Fuse 2 x 40 A
Power Supply Voltage 11÷15 VDC
Stage Bandwidth (-3 dB) A, B Ch: 5 ÷ 50k Hz <br> -3 dB) C (sub) Ch: 5 ÷ 500 Hz
Stage Distortion 0.08 %
Stage Sn Ratio (A weighted @ 1V) A, B Ch: 100 dB <br> (A weighted @ 1V) C (sub) Ch: 106 dB
170 x 349 x 46.70 / 6.69” x 13.74” x 1.84”
Sub Channel (-50 ÷ 6) dB
6 5 Ch: 70 W x 4 + 380 W x 1 (4Ω) <br> 5 Ch: 100 W x 4 + 550 W x 1 (2Ω) <br> 3 Ch: 200 W x 2 (4Ω) + 380 W x 1 (4Ω) <br> 3 Ch: 200 W x 2 (4Ω) + 550 W x 1 (2Ω) <br>
Remote Sub Volume (-50 ÷ 6) dB
950 W total power
4 x 100 + 1 x 550 W @ 2ohm
D-class
950
4x100W+1x550W
-
575,0000
AMPLIFIER
