audison

TH uno

1500 W total power | 1 x 2300 W @ 1ohm | A-class
Was:
€3 200,00
Out of stock
Free shipping from 100€
Free returns within 60 days
3-year warranty

Description

Thesis amplifiers are born with the know-how and experience achieved with the HV venti, improved by the innovation of digital technology. The result is a perfect combination between the highest level of analog technology and the advanced features of the digital technology in one unique product. The precious synergy with Full DA HD technology takes the in-car listening experience to a new level of excellence; the synthesis of a unique know-how employed in mobile audio reproduction.TH uno is a single channel (mono) amplifier used to achieve maximum performance under any load; capable of delivering up to 2300 W into 1 ohm and 200 W in the audiophile A Class mode. Specifically designed to drive systems and subwoofers with self-assured mastery.
Dimension 1 510
Dimension 2 478
Dimension 3 259
Dimension 5 160
TH uno - MONO AMPLIFIER 1x1500W
<ul><li>Complementary differential circuitry with current mirror. </li><li>Cascode A Class driver with inverted complementary triplet power stages. </li><li>Integrated 24-bit / 192 kHz Hi-End DA converters. </li><li>Compatibility with Audison Full DA
Channels 1
Removable kit: (Hi-pass / Lo-pass / Bandpass 12/24dB) 32 steps 18 ÷ 7.5k Hz with 8 standard & 2 customizable modules
Fuse 150 A
Power Supply Voltage 11 ÷ 15 VDC
Stage Bandwidth (-3 dB, 2 VRMS, 4 Ω): 5 ÷ 40k Hz
Stage Distortion 0.01 %
Stage Sn Ratio (A weighed @1 V): 106 dBA
259 x 510 x 67 / 10.2 x 20 x 2.6
6 • 850 W x 1 (4Ω) <br> • 1500 W x 1 (2Ω) <br> • 2300 W x 1 (1Ω) <br>
1500 W total power
1 x 2300 W @ 1ohm
A-class
1500
1x1500W
-
3200,0000
AMPLIFIER
